Aquaplus JF

Easy access to compliant laboratory water

Aquaplus JF series ultrapure water dispenser combines pretreatment unit, reverse osmosis unit, ultrapure purification unit, dual wavelength UV lamp and terminal ultrafiltration column into a single unit, designed for laboratories and suitable for all kinds of analytical experiments.

With Aquaplus JF you can......

  • 1.Tap water intake, automatic continuous water production, greatly meet the water needs of the laboratory.
  • 2.Modular and quick intermal design, small footprint, beautiful appearance, easy to install and maintain. Pre-treatment, reverse osmosis, purification column and post-processing unit are all independent structures, which makes cartridge replacement and system maintenance more convenient.
  • 3.Pre- treatment adopts 5μm PP cartidge and coconut shell activated carbon cartridge, which efectively protects RO membrane.
  • 4.The RO membrane component with original imported membrane of Dow DOW, ion exchange resin, polished nucleus grade resin, silent high pressure pump, inlet solenoid valve, etc, the product performance is guaranteed to the maximum.
  • 5.Visual display of operating status, easy to operate.
  • 6.Power on self-test, water shortage protection alarm, automatic power failure reset, automatic shutdown after the pure water tank is full, ultra-low pressure protection, UV lamp failure alarm, etc, to provide safety assurance.
  • 7.RO membrane anti-scaling cleaning function and manual forced rinsing program to maximize the service life of RO membrane.
  • 8.Quickly achieve 18.25MQ.cm@25°C stable water quality, saving water, electricity and time.
  • 9.Water quality online monitoring system, can instantly measure the water qualit of produced water.
  • 10.Can be selected when taking water programmed design, eliminating manual water waiting.
  • 11.Optional RS232 interface, record the history of water quality.
  • 12.Optional pressure barrel of different capacity.
  • (Learn more)

Water quality
B M H
Type I Water Resistivity (25°C ) 18.2MQ.cm
Grade III Water Conductivity(25°C) RO去除率>96%,2-10μS/cm
Baecteeria3 <0.1cfu/ml <0.001cfu/ml
Baecteerial endotoxin3 <0.001EU/ml
Particles(>0.2μm) <1/ml <1/ml <1/ml
1. Under the condition of feed water TOC < 50ppb and proper operation conditions.
2. With UV device and ultra-precision filtration module, under regular cleaning and maintenance.
Water production volume specifications
Secondary reverse osmosis water production volume (25°C)     5L/h、10L/h、15L/h、20L/h
Water withdrawal flow rate     1-2L/min
Water intake requirements
Water Source     tap water
Flow rate     ≥100L/h
Conductivity(25°C)     <1000μS/cm
Pressure     1-5bar
Temperature     5-35°C
Free chlorine     <1ppm
PH value     6.5-8.5
Total hardness(by CaCO3)     <450ppm
Electricity requirement
Power Supply     220V/50Hz
System power     100W
Size and weight
Dimesion(H×W×D)     520×280×470mm
Packing weight     25Kg
*All information and descriptions on the official website represent only the general functions and parameters of the equipment, and are subject to the technical leaflets or bid documents provided by the company.
